• PH-812 / 2K4 system
• House Model, B/W or Color System
• Video Intercom
• 2-wire, non-polarity system
• Aluminium / Plastic Camera
• Max 2 Cameras to 3 Monitors
• Dust protect and water proof cover design of Camera
• 6/12 infrared LEDs let you see clearly at night
• Inter-communication is available

• Power In: Supply from PH-812M
• Resolution: Colour- 480 TV line
  B/W- 500 TV Line
• Lens: Pin hole Lens, Auto
• CCD: 1/3" Colour or B/W CCD
• Min. illumination: Colour-0.1Lux
  B/W-0.1Lux (w/ 6pcs Infrared IR)
• Dimensions: 100x180x25mm
• Packing:0.06 cubic ft
• Weight: 1.0 kg
• Do not need Prebox (Surface Type)
• Stainless case

• Pin Hole Type Camera
• Power In: Supply from PH-812M
• Resolution: Colour- 480 TV line , B/W- 500 TV Line
• Lens: Pin hole Lens, Auto
• CCD: 1/3" Colour or B/W CCD
• Min. illumination: Colour-2 Lux , B/W-1Lux
• Dimensions: 230x150x2(47)mm
• Packing:0.08 cubic ft
• Weight: 1.0 kg
• Prebox (230x150x47mm) (Flush Type)
• Stainless case

• Pin Hole Type Camera
• Power In: Supply from PH-812M
• Resolution: Colour- 480 TV line , B/W- 500 TV Line
• Lens: Pin hole Lens, Auto
• CCD: 1/3" Colour or B/W CCD
• Min. illumination: Colour-0.1Lux
  B/W-0.1Lux (w/ 6pcs Infrared IR)
• Dimensions:230x150x2(47)mm
• Packing:0.08 cubic ft
• Weight: 1.0 kg
• Prebox (230x150x47mm) (Flush Type)
• Stainless case

• Power in: DC12~15V Non-polarity
• Wiring: 2-wire, Non-Polarity from Camera
• Dimension: 130X90X40 mm

• Resolution: Colour- 480 TV line
  B/W- 500 TV Line
• Lens: AUTO
• CCD: 1/3" B/W or Color CCD
• Min. illumination: 0.1 lux with 12pcs IR
• Dimension: 240X120X60 mm
• need A or B type prebox

• Resolution: Colour- 480 TV line
  B/W- 500 TV line
• Lens: AUTO
• CCD: 1/3" B/W or color CCD
• Min. illumination: 0.1 lux with 6pcs IR
• Dimension: 110X68X30 mm
• No need the Prebox

• Power in: DC18V by Adaptor
• CRT: 4" B/W flat type CRT
• Resolution: 500 TV lines
• Calling tone: Ding-Dong tone
• Display time: about 30 sec.
• Power consumption:
• Standby-200mA Operating-600mA
• Wiring: 2-wire, non-polarity
• Dimension: 210X225X55 mm
• Wiring distance: 1.0mm D-50M / 165 FT
• Color System:
  4" TFT LCD Panel, 65k colors
  105,196 pixels /442HX238V

• Power in: DC15V by Adaptor
• CRT: 4" B/W flat type CRT
• Resolution: 500 TV lines
• Calling tone: Ding-Dong tone
• Display time: about 30 sec.
• Power consumption:
• Standby-200mA Operating-600mA
• Wiring: 2-wire, non-polarity
• Dimension: 210X225X55 mm
• Wiring distance: 1.0mm D-50 M/ 165 FT
• Color System:
  4" TFT LCD Panel, 65k colors
  105,196 pixels /442HX238V

• Handsfree Main-Monitor
• Power In: DC15V
• Screen: Colour- 3.5" Diagonal Color TFT LCD Panel
• Resolution: 480H X 234V dot
• Active Area: 72(W)x50.554(H)(mm)
• View Angle: Top: 10deg.; Bottom: 30deg.;left / Right: 45deg.
• Calling tone: Ding-Dong tone
• Consumption: standby 200mA. operating 450mA.
• wire: 2 wires only
• Dimension:130/205/45 mm
• Packing: 0.2 cubic ft
• Weight: 0.7 kg

• Handsfree Sub-Monitor
• Power In: DC15V
• Screen: Colour- 3.5" Diagonal Color TFT LCD Panel
• Resolution: 480H X 234V dot
• Active Area: 72(W)x50.554(H)(mm)
• View Angle: Top: 10deg.; Bottom: 30deg.;left / Right: 45deg.
• Calling tone: Ding-Dong tone
• Consumption: standby 200mA. operating 450mA.
• wire: 2 wires only
• Dimension:130/205/45 mm
• Packing: 0.2 cubic ft
• Weight: 0.7 kg

• Handsfree Main-Monitor
• Power In: DC15V
• Screen: Colour- 3.5" Diagonal Color TFT LCD Panel
• Resolution: 480H X 234V dot
• Active Area: 72(W)x50.554(H)(mm)
• View Angle: Top: 10deg.; Bottom: 30deg.;left / Right: 45deg.
• Calling tone: Ding-Dong tone
• Consumption: standby 200mA. operating 800-1,000mA.
• wire: 2 wires only
• Dimension:130/280/45 mm
• Packing: 0.3 cubic ft
• Weight: 1.0 kg

Video Recorder (New Version)
Video recorded with a device that is compatible with MPEG-4.(Linux format)
Resolution : 640*480  30FPS per second
Memory Card: 4GB (SDHC Card) , the max. is up to 16GB
System: PAL or NTSC
Language: English
