PH-912 House Model, Anti-Burglar Video Door phone System
  • 4-wire Anti-burglar Color system (CAT 5 Available).
  • Max. capacity is 4:4 system(4 cameras and 4 monitors) per house.
  • Designated call to any one of monitors .
  • Single announcement to any one of monitors or group announcement to all monitors.
  • Screen switch monitoring all cameras status in monitor or fix to monitor one camera only.
  • 24 hours monitoring or 3 minutes monitoring.
  • Screen switch monitoring, the default value : 2 sec., 3, 4, 5, 6, 7,8, &10 sec. depends your requirement.
  • The monitoring mode still keep monitoring even visitor makes a call from camera to monitor.
  • Camera call monitor, if nobody gets the call in monitor side, after 30 sec. the monitor will be off automatically. If someone gets the call, the talking time is 3 min., over 3 min. the screen off automatically.
  • A call coming, just one of monitors gets the call, the ringing of other monitors will be stopped immediately.
  • There are many modes in this system, monitoring mode, intercom mode, announcement mode & talking mode…etc. But "Priority call-in" is primary .For example, If you install 4 cameras and 4 monitors. Camera no.1 call coming and you are talking to camera no.1, at the same time, camera no.3 call coming,too. The talking with camera no.1 will be stopped immediately. Camera no.3 call is prior to talk.
  • “returned calling” you can hear on camera when you are pressing camera.
  • "Panic Call" can be heard from camera and monitor both.
  • Monitor with remote function - get a call / open door/ panic button by remote.
  • The brightness/color/contrast adjustment of monitor screen by digital way.




PH-912C12a Stainless steel Color Camera
PH-912CAL Aluminum color camera

Pinhole type

  • Will be Release
  • Power In: From 912CS1/CS4
  • Resolution: Color- 480 TV line
  • Lens: Pin hole Lens, Auto
  • CCD: 1/3" Color
  • Min. illumination: Color-0.1 Lux with white LEDs
  • Dimensions: 230x150x2(47)mm
  • Packing:0.06 cubic ft
  • Weight: 1.0 kg
  • Need Prebox (Flush or surface mounting Type)
  • Stainless steel front panel

  • Power In: From 912CS1/CS4
  • Resolution: Color- 480 TV line
  • Lens: Auto
  • CCD: 1/3" Color
  • Min. illumination: Color-0.1 Lux with white LEDs
  • Dimensions: 230x150x2(47)mm
  • Packing:0.06 cubic ft
  • Weight: 1.0 kg
  • Need Prebox (Flush or surface mounting Type)
PH-912CPL ABS color Camera
PH-912Mi 4" Color Handsfree Monitor



  • Power In: From 912CS1/CS4
  • Resolution: Color- 480 TV line
  • Lens: Auto
  • CCD: 1/3" Color
  • Min. illumination: Color-0.1 Lux with white LEDs
  • Dimensions: 140x105x45mm
  • Packing:0.03 cubic ft
  • Weight: 0.5 kg



  • Handsfree Monitor
  • Remote function : get a call / open door/ panic button
  • Power In: From 912CS1/CS4
  • Screen: Wide viewing angle, Color- 4" TFT LCD Panel
  • Resolution: 480H X 234V dot
  • Active Area: 72(W)x50.554(H)(mm)
  • Dot Pitch: 0.150(H)x0.216(V)(mm)
  • View Angle: Top: 10deg.; Bottom: 30deg.;left / Right: 45deg.
  • Calling tone: 10 kinds of melodies
  • Consumption: standby 200mA. operating 450mA.
  • Dimension:130/205/45 mm
  • Packing: 0.2 cubic ft
  • Weight: 0.7 kg
  • 3 kinds of different colors for choosing in side cover
PH-912CS1 Camera Selector   PH-912CS4 Multi-Camera Selector

  • for 1 Camera and 1 Monitor
  • Built-in power inside
  • Any kind of Cameras and Monitors in the series of PH-912 system are available.
  • Dimension:107Wx156Lx50Hmm


  • For 2 to 4 Cameras
  • Built-in power inside
  • Always open the door you are watching
  • Any kind of Cameras and Monitors in the series of PH-912 system are available.
  • Dimension:107Wx156Lx50Hmm

PH-912Mg Handsfree Audio Unit
PH-912DS   Door lock control box (for PH-912CPL only)

  • New Release
  • Handsfree audio unit
  • Power: DC15V
  • Calling tone: 10 kinds of melodies
  • Consumption: standby-100mA. operating 300mA.
  • Dimension: 210X95X40 mm
  • Packing: 0.2 cubic ft
  • Weight: 0.5 kg

  • for PH-912CPL only
  • Power: AC110~250V
  • Dimension:107Wx156Lx50Hmm
