Video Doorphone for 4 Cameras connect to 3 Monitors
Security Alarm Digital Video Doorphone
Color CCTV Camera
KVM-301 Video Memory

The functions of S600 Home security unit:

A existed "MK755" Home security video doorphone system , there are 3 supervised zones in "MK755" system. This system entered market for 5 years, it is not enough to meet all customer's requests and market demand variations. Thus we are working out a brand-new Home security Alarm system. The whole system will be completed about July or August 2001. At present, a single Home Security Unit "S600" for each apartment (or a single house ) had been finished .

The features of S600 as follows:

  • 7 supervised zones (3 24hrs zones for gas / fire detector and panic, 4 zones for anti-burglar zones) in system; the 1st anti-burglar zone can be made a delayed set and a switch for starting the system.
  • It can be set the delay time of arm/dis-arm separately, the setting time as 30/40/50/60/70/80/90/100/120 sec. And before 15/10/5 sec. of reach the dis-arm time, internal sounder will sound for reminding entry delay.
  • Arm / dis-arm anti-burglar system can be controlled by password/ remote controller/all kinds of card reader machines for controlling, you can choose one of them to arm / dis-arming anti-burglar system.
  • The" arming anti-burglar system" to clear alert system, its intelligent design fully protect your password. You can setting the the Password from 1 digit to 8 digits.
  • In case of evildoer forces you to dis-arm anti-burglar system, the "anti-forced function" can help you sending a SOS message to guard.
  • The "Wireless Panic function" (optional function) can help your aged parents when they meet urgent status. Wear a remote controller, pressing panic button immediately on remote controller when they meet any emergency inside the house. At the same time, S600 will send an alarm sound and a SOS message to guard room. Let guard helps them in time.
  • "Arming at home": A human function; arbitrarily choose anti-burglar zones as alert system from 4 zones.
  • " Mute": An intelligent design, the "mute" key will lose its function while the system is going to alert system for preventing evildoer invade your house and switch off sound.
  • "Visitor notice": To start or no start as your choice.
  • "S600"has doorbell function; just connect the wire of doorbell to"S600".
  • 3 kinds of alarm sounds for choosing, you can set different alarm sound as on behalf of different status.
  • Output way: by RS485, by dry contact or KANRICH own system.
  • Output: (optional function) external siren, external emergency battery & the DC12V power supply for PIR, we prepare these functions for use in advance.
S601 Home Security Unit
S602 Home Security Unit
S601 Home Security Unit
S602 Home Security Unit

For Kanrich Software of Control Center

  • Power: DC12~15V 500mA
  • Supervised Zones: 3 24hrs zones for gas, fire detect and panic, 4 zones for anti-burglar zones in system
  • Mute: When mute LED on, the system keep silence
  • Bell: To start or stop as your choice when open the door
  • Password: Its intelligent design of Password, you can setting the the Password from 1 digit to 8 digits.
  • Home: Arm at home, you can arbitrarily choose any anti-burglar zone to alert from 4 anti-burglar zones
  • Doorbell: It has doorbell function, just connect the wire to push button
  • Output: By RS485 to Kanrich own system
  • Emergent call: 3 different kinds of sounds for Panic, Fire and Anti-burglar zone
  • Emergent call time: The music off after 90 sec., but memorize the situation in LED
  • Wiring: 2 wires in polarity to system
  • Arm / dis-arm anti-burglar zones: Delay or immediately by keypad password or all kinds of card readers
  • Delay arm/dis-arm time: It can be set the delay time of arm/dis-arm separately, the setting time as 30/40/50/60/70/80/90/100/120 sec. And before 15/10/5 sec. of reach the dis-arm time, internal sounder will sound for reminding entry delay
  • Dimension: 220X100X45mm
  • Packing: 0.2 cuft, 0.4kg
  • Optional Items: Extra Siren, extra Battery, AC/DC12V Adaptor, PIR and Magnetic Switch

For Non-Kanrich Software of Control Center

  • Power: DC12~15V 500mA
  • Supervised Zones: 3 24hrs zones for gas, fire detect and panic, 4 zones for anti-burglar zones in system
  • Mute: When mute LED on, the system keep silence
  • Bell: To start or stop as your choice when open the door
  • Password: Its intelligent design of Password, you can setting the the Password from 1 digit to 8 digits.
  • Home: Arm at home, you can arbitrarily choose any anti-burglar zone to alert from 4 anti-burglar zones
  • Doorbell: It has doorbell function, just connect the wire to push button
  • Output: dry contact point for Panic, Fire, Anti-burglar zone and common point
  • Emergent call: 3 different kinds of sounds for Panic, Fire and Anti-burglar zone
  • Emergent call time: The music off after 90 sec., but memorize the situation in LED
  • Wiring: 5-wires (4 dry contact points for Panic, Fire, Anti-burglar zone, common point and GND)
    Arm / dis-arm anti-burglar zones: Delay or immediately by keypad password or all kinds of card readers
  • Delay arm/dis-arm time: It can be set the delay time of arm/dis-arm separately, the setting time as 30/40/50/60/70/80/90/100/120 sec. And before 15/10/5 sec. of reach the dis-arm time, internal sounder will sound for reminding entry delay
  • Dimension: 220X100X45mm
  • Packing: 0.2 cuft, 0.4kg
  • Optional Items: Extra Siren, extra Battery, AC/DC12V Adaptor, PIR and Magnetic Switch
S601R Remote Control Home Security Unit
S602R Remote Control Home Security Unit
1 For Kanrich Software of Control Center
  • Power: DC12~15V 500mA
  • Supervised Zones: 3 24hrs zones for gas, fire detect and   panic, 4-zones for anti-burglar zones in system
  • Mute: When mute LED on, the system keep silence
  • Bell: To start or stop as your choice when open the door
  • Password: Its intelligent design of Password, you can setting the the Password from 1 digit to 8 digits.
  • Home: Arm at home, you can arbitrarily choose any anti-burglar zone to alert from 4 anti-burglar zones
  • Doorbell: Its has doorbell function, just connect the wire to push button
  • Output: By RS485 to Kanrich own system
  • Emergent call: 3 different kinds of sounds for Panic, Fire and Anti-burglar zone
  • Emergent call time: The music off after 90 sec., but memorize the situation in LED
  • Wiring: 2 wires in polarity to system
  • Arm/ dis-arm anti-burglar zones: Delay or immediately by Remote control / keypad password / all kinds of card readers
  • Delay arm/dis-arm time: It can be set the delay time of arm/dis-arm separately, the setting time as 30/40/50/60/70/80/90/100/120 sec. And before 15/10/5 sec. of reach the dis-arm time, internal sounder will sound for reminding entry delay
  • Accessory: Remote Control 2 pcs for Arm/dis-arm, Panic and Soundless Panic functions (3 kinds of functions)
  • Note: Every one S601R can set max. 6 pcs Remote Controls (R.C.). If you request more than 6 pcs R.C., Please contact us.
  • Dimension: 220X100X45mm
  • Packing: 0.2 cuft, 0.4kg
  • Optional Items: Extra Siren, extra Battery, AC/DC12V Adaptor, PIR and Magnetic Switch

For Non-Kanrich Software of Control Center

  • Power: DC12~15V 500mA
  • Supervised Zones: 3 24hrs zones for gas, fire detect and panic, 4-zones for anti-burglar zones in system
    Mute: When mute LED on, the system keep silence
  • Bell: To start or stop as your choice when open the door
  • Password: Its intelligent design of Password, you can setting the the Password from 1 digit to 8 digits.
  • Home: Arm at home, you can arbitrarily choose any anti-burglar zone to alert from 4 anti-burglar zones
  • Doorbell: Its has doorbell function, just connect the wire to push button
  • Output: dry contact point for Panic, Fire, Anti-burglar zone and common point
  • Emergent call: 3 different kinds of sounds for Panic, Fire and Anti-burglar zone
  • Emergent call time: The music off after 90 sec., but memorize the situation in LED
  • Wiring: 5-wires (4 dry contact points for Panic, Fire, Anti-burglar zone, common point and GND)
    Arm/ dis-arm anti-burglar zones: Delay or immediately by Remote control / keypad password / all kinds of card readers
  • Delay arm/dis-arm time: It can be set the delay time of arm/dis-arm separately, the setting time as 30/40/50/60/70/80/90/100 /120 sec. And before 15/10/5 sec. of reach the dis-arm time , internal sounder will sound for reminding entry delay
  • Accessory: Remote Control 2 pcs for Arm/dis-arm, Panic and Soundless Panic functions (3 kinds of functions)
    Note: Every one S602R can set max. 6 pcs Remote Controls (R.C.). If you request more than 6 pcs R.C., Please contact us.
  • Dimension: 220X100X45mm
  • Packing: 0.2 cuft, 0.4kg
  • Optional Items: Extra Siren, extra Battery, AC/DC12V Adaptor, PIR and Magnetic Switch
S600DB Data Box
S611 Siren with Strobe
S615 Magnetic Switch
  • With hardware and software: software Win98, please read user manual for getting more detailed information
  • Dimension:107Wx156Lx50Hmm

  • Power:DC10~14V 300mA
  • S.P.L. (dB/M):105 dB/M
  • Wiring:2 wires in polarity to system
  • Dimension:122 X 73 X 43 mm
  • No need power supply, allowable distance 3 cm , N.C. type

S616 Remote Control

  • S616 remote controller is the same as the standard accessory, set and usage, please read user manual
S617 AC/DC12V Adaptor
S612 Passive Infrared Detector (PIR)
485 / 232 Convertor
  • Power: AC100/110/120/220/230V
  • Output: DC12V 1.2A
  • Notice: The adaptor only offers this home security system , PIR, siren and all accessories . Don't external connect the products which are not belong to this system , otherwise the system will be crashed.
  • Power:DC9~16V
  • Detection range:15 X 15 M at 25℃
  • Alarm output:N.C, 30VDC, 0.2A max.
  • Alarm time:3 sec. (+/-1sec.)
  • Consumption:13mA, 12VDC
  • Detectable speed:0.3~1.5m/sec.
  • Wiring:2 wires in polarity to system
  • Dimension:100 X 60 X 42 mm
  • Weight:78gm
  • Power: DC15V/ 200mA
  • Input: From 168CB (485)
    Output:  To RS232 socket

  • Win98 or Win2000 system
  • Dimension: 100X65X45 mm
